Installation instructions – Reznor R6GP Option - Installation - Roof Curb - Lt Commercial User Manual
Page 4
CURB FRAME
CANT STRIP
(FIELD SUPPLIED)
WOOD NAILER
COUNTER FLASHING
(FIELD SUPPLIED)
ROOFING FELT
(FIELD SUPPLIED)
RIGID INSULATION
(FIELD SUPPLIED)
ROOF INSTRUCTIONS
NEICRB07
SUPERSEDES 08-26-08
DECEMBER 6, 2010
INSTALLATION INSTRUCTIONS FOR
547860 / 547861 / 547862 / 547863
ROOF CURBS USED WITH Q5SN/Q6SP 090-120
R6GP/P6SP 072-120 / GR4GN/GP4SN 090-120 UNITS
INSTALLATION
INSTRUCTIONS
