Parts List
ITEM QTY. PART NO.
DESCRIPTION
NO.
1
1
AF-18899
Weldment, Console Back Plate
2
1
AL-18945
Front Roller, 3.0” O.D.
3
1
AL-18946
Rear Roller, 3.0” O.D.
6
1
AX-17578
Assembly, Contact Grip, Pair
7 1
AF-18394 Weldment,
Elevation
8 1
AX-18729 Assembly,
Idler
9 1
AX-19150 Assembly,
E-Stop
Lanyard
10 1
AX-19239 Assembly,
Motor
Cover
11 1
BD-19642 Belt,
Running
12 1
BD-18917 Belt,
Poly-V,320J8
15
2
DE-19360
Decal, Side Labels, “Cybex”, Black
15
2
DE-19353
Decal, Side Labels, “Cybex”, Silver
17 1
DK-19641 Deck,
Running
18 1
EC-18573 Sensor,
Speed
19 1
EH-00986 Wire
Tie,
9”
20 1
EH-10291 Base,
Wire
Tie
21 1
FM-18405 Shaft,
Elevation
22
4
FS-16511
Plate, Rear Rubber Foot Mounting
23
1
FS-19731
Plate, Cable Connector, 445T
24
1
FT-16825
Sleeve, Elevation Mounting, Top
25
1
FT-16826
Sleeve, Elevation Mounting, Bottom
26
2
HB-16367
Bushing, .50 I.D. x .62 O.D. x .31 LG, Flanged
27
2
HN-10029
Nut, 1/2 - 13 HEX STL ZINC
28
2
HN-17935
Nut Locking, 3/8 - 24, GRD C, STL, ZN
29
2
HS-00156
Screw, 4-40 x .62, PNHD PHIL
30
2
HS-00261
Bolt, 1/2 - 13 x 5.5, HXHD
31
6
HS-15706
Screw, 8-16 x .50, PNHD, STL, BLK ZN CLR, TYP WB
32
10
HS-16509
Screw, SLFTP, 10 x .5, PNHD, PLT, TYP B, PT-S
33
10
HS-16628
Bolt, 1/4 - 20 x 1.5, HXHD, G8
34
6
HS-16929
Bolt, Whiz Lock, 3/8 - 16 x .625, HXHD, G5
35
8
HS-16939
Screw, SEMS,10/32 x .75, PNHD, BLK ZN, EXT
36
1
HS-17936
Bolt, 3/8 - 24 x 2.0, HXHD CAP, G8, YEL ZN
37
1
HS-17937
Bolt, 3/8 - 24 x 2.75, HXHD CAP, G8, YEL ZN
38
4
HS-19108
Screw 5/16-18 x 3/4, HXHD, Whiz-Lock
39
1
HS-41006
Screw, SLFTP, 10/24 x 1.38, PNHD PHIL, SST, BLK, TT
40
2
HS-41107
Bolt, 5/16 - 18 x 1.5, BTHD, SST, BLK
41
2
HW-00165
Washer, Split Lock, 5/16, ZINC
42
8
HW-00180
Washer, Split Lock, 1/4, SST, BLK
43 2
HW-00590 Bushing,
Nylon,
1/2
44
12
HW-18123
Washer, .344 I.D. x .75 O.D. x .125 Thick, Black Zinc
45
6
HX-13771
Ring, Retaining, 5/8 x .579 FR. I.D.
46
2
HX-15678
Bushing, Deck, 5/16 - 18
47
1
HX-17711
Plug, Plastic, 7/16, BLACK
48
4
HX-17788
Tape, Double Sided, .032 Thick
50
2
HX-18901
Grips, 445T Upright Handrail
51 1
HX-19052 Idler
Spring
52 2
HX-19102 Rubber
Foot,
Rear
53
1
HX-19384
Coupling, Shaft, DBL Split 5/8
56 1
PL-18773 Plunger,
E-Stop
57
1
PL-18929
Cover, Rear, Outer Right
58
1
PL-18930
Cover, Rear, Inner Right
59
1
PL-18932
Cover, Rear, Outer Left
60
1
PL-18933
Cover, Rear, Inner Left
61
1
PL-18990
Cover, Motor, Front, 445T
62
1
PL-18991
Cover, Motor, Right ,445T
63 1
PL-18992 Cover,
Motor
Left,445T
64
1
PL-19061
Cover, Console, Back Trim, 445T
65 1
PL-19093 Cover,
Handle
Lower
66
1
PL-19094
Accessory Tray, 445T Console
68 1
SW-18535 Switch,
Limit
70
8
HS-11977
Screw, SEMS, 8/32 x .38, PNHD
74
2
CW-16712
Wheel, 3 Dia. x 1.25 W, Plain Bearing
75 4
HB-18768 Bearing,
LF-1011-12
