PS Engineering
PMA7000CD- Series Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-790-0010
Page 1-4
Revision 10, September 2005
Compact Disc Player PCD7100-R, P/N 11959
TSO Compliance
C50c, Class A
Environmental Compliance
B1CABSRXXXXXXABBBBTMXXE2
Operating Temperature Range::
-15º C to 55ºC
Altitude:
Up to 25,000 feet in a non-pressurized area
DIMENSIONS:
Height: 1.5 in. (3.8 cm) Width: 6.25 in. (15.9 cm)
Depth: 7.8 in. (19.8 cm)
WEIGHT (With Rack & Connectors):
1.9 lb. (.54 kg)
1.6 EQUIPMENT
SUPPLIED
1 ea. of the following units:
Model Description
Part
Number
PMA7000S-CD MP3
PMA7000S Audio Panel with Stereo Intercom for use with
PCD7100-R, Silver trim. NO MARKER beacon receiver.
7000S - Opt CD
PMA7000CD MP3
PMA7000CD Audio Panel with Marker Beacon and Stereo inter-
com for use with PCD7100-R. Silver trim ring.
7000MS – Opt CD
Option 1
Adds 1-minute continuous-loop digital recorder
PCD7100-R
Same as above, but with MP3 capability
11959
Option 3
Black bezel units (No silver trim)
PMA7000CD Installation Kit: 250-007-3613
Description Quantity
Part
Number
PMA7000CD installation rack assembly
1
120-430-0420
Top Molex Connector Shell w/key, 44 pin, key 4/5
1
120-425-4402
Bottom Molex Connector Shell w/key, 44 pin, key 7/8
1
120-425-4400
Gold Plated Crimp Pins
88
425-001-0002
4 40 X 7/16 screw w/nylon patch
4
475-440-0007
Grounding bar
1
430-007-0001
6-32 X 3/4 pan head Phillips screw
2
475-632-0038
6-32 Nut Flat
2
475-632-0003
6-32 Lock Nut
2
475-632-0004
Cable Clamp
1
625-001-0002
#6-32 x ½” Flat head Phillips screw
6
475-632-0012
#6-32 Clip Nut
6
475-630-0002
Parts identification sheet
1
002-250-7028
PCD7100-R Remote Player (11959) Installation Kit
Part Number
Description
250-795-0005
430-795-0020 Tray
1
425-015-2052
DB 15 Pin Connector Shell
1
425-020-5090 Crimp
Sockets
15
425-015-0003 Connector
Hood
1
475-632-0012
#6-32 x ½” Phil screw.
4
475-630-0002
6-32 Clip Nut
4
475-013-0001 #4-40
Kep-Nut
2
470-440-0018 #4-40
Screw
2
1.7
EQUIPMENT REQUIRED BUT NOT SUPPLIED
a)
Circuit Breaker: 1 ea; 3 amp PULL TYPE REQUIRED for PMA7000CD
