PS Engineering PMA7000CD Installation Manual - Manual (Page 40)

PS Engineering
PMA7000CD Audio Selector Panel and Intercom System
With PCD7100-R Remote Compact Disc Player
Installation and Operator’s Manual
200-790-0010 Appendix G September 2005
Cross-reference for GMA340
GMA34
0 PMA7000B
GMA34
0 PMA7000B
J1 J2
J1 Function J2 Function Bottom Top
1 Mkr Ant B 1 Pilot Phones Lo 1
2 Mkr Ant Lo A 2 Copilot Phones Lo B
3 Com 3 Audio in J 3 Copilot Phones (L) 3
4 Com 3 Lo 1* 4
Copilot Phones
(R)
2
5 Com 3 Mic Audio K 5 Lights lo E
6 Com 3 Mic Key 15 6 14/28 V Lights F
7 ADF Audio In S 7 14/28 V Lights D
8 ADF Audio Lo 1* 8 Aircraft Power 20
9 Com 1 Audio 9 9 Aircraft Power 20
10 Com 1 Audio Lo 1 10 Aircraft Ground Z
11 Com 1 Mic P 11 Aircraft Ground Z
12 Com 1 Mic Key R 12 PA Mute 18
13 Com 2 Audio 10 13 Mute Inhibit V
14 Com 2 Audio Lo 1 14 Mute Inhibit Lo Z
15 Com 2 Mic H 15 No Connect
16 MASQ U 16 Pilot Phones (L) 3
17 Nav 1 Audio 12 17 8 ohm select n/c
18 Nav 1 Audio Lo 1 18 Reserved
19 Nav 2 Audio 13 19 Tone Enable n/c
20 Nav 2 Audio Lo 1 20 Swap 10
21 DME Audio 6 21 Swap Lo Z
22 DME Audio Lo 1 22 No Connect
23 Com 3 Spkr Load n/c 23 Music 1 (L) 15
24 Com 3 Spkr Load n/c 24 Music 1 (R) 16
25 Com 1 Speaker Load 19 25 Music 1 Lo T
26 Com 1 Speaker Load L 26 Music 2 (L) 13
27 Com 2 Speaker Load 16 27 Music 2 (R) 14
28 Com 2 Speaker Load M 28 Music 2 Lo R
29 No Connect n/c 29 No Connect
30 Com 2 Mic Key V 30 No Connect
31 Unswitched Unmuted 1 T 31 Pilot Phones(Rt) 1
32
Unswitched Unmuted
Lo
1 32 Copilot Mic Audio 8
33 Pilot Mic Audio 8 33 Copilot Mic PTT 9
34 Pilot Mic PTT Y 34 Copilot Mic Lo K
35 Pilot Mic Lo 1 35 Pass 1 Mic Audio 4
36 Ext IM MKR C 36 Pass 1 Mic Lo D
37 Ext OM MKR 5 37 Pass 2 Mic Audio 5
38 Ext MM MKR 4 38 Pass 2 Mic Lo E
39 MM Sense 2 39 Pass 3 Mic Audio 6
40 Pass HP (L) 11 40 Pass 3 Mic Lo F
41 Pass HP (R) 12 41 Pass 4 Mic Audio 7
42 Pass HP Lo N 42 Pass 4 Mic Lo H
43 Unswitched 2 Lo 1 43 Speaker Lo 22
