PS Engineering
PMA450 Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-450-0000 Page 1-4 Rev. 3, November 2014
PMA450 Installation Kit: 250-890-0000
Description Quantity Part
Number
Installation rack assembly 1 430-890-0040
Rack back plate 1 430-890-0050
44-pin connector kit 2 120-891-2045-
Backshell, connector 2 625-025-2465
Backshell Retainer 2 431-881-0100
4 40 X 7/16 screw w/nylon patch 4 475-440-0007
4 40 X 3/8 screw w/nylon patch 4 475-440-1038
4-40 x ¼” screw with lock washer 2 475-440-0001
Solder Lug 2 475-009-0001
Cable Clamp 1 625-001-0002
#6-32 x ½” Flat head Philips screw 6 475-632-0012
#6-32 Clip Nut 6 475-630-0002
1.7 EQUIPMENT REQUIRED BUT NOT SUPPLIED
a. Circuit Breaker: 1 ea; 5 amp PULL TYPE REQUIRED for PMA450
b. Isn’t this optional? You’re not required to have speaker are you? Speaker, 4

c. Headphone Jacks (Stereo, as Required)
d. Microphone Jacks (as Required)
e. Headphones, 150
 (Stereo), up to 6 as required
f. Microphones, up to 6 as required
g. Marker Antenna (75 MHz, VSWR <1:1.5, and appropriate for the airspeed) (-0100 Only)
h. Interconnect Wiring
1.8 LICENSE REQUIREMENTS
None
PMA450 Bluetooth™ Radio approval:

FCC ID: QOQWT32AE

Industry Canada ID: 5123A-BGTWT32AE

CE EMC Directive 89/336/EEC as amended by Directives 92/31/EEC and 93/68/EEC
