PS Engineering Inc. ®
PAR100EX Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-760-0000
Page 1-3
Rev. 12, Jan. 2014
Receiver sensitivity
-12dB SINAD @ 0.3µV (1KHz audio with 70%
modulation)
Receiver Selectivity
-70dB
Squelch Range
0.5 - 10.0µV
Data Interface
RS232
Speaker volume output
Nominal 4 watts output to 4 ohms
Headset volume output
Nominal 100 milliwatts output to 600 Ω
Temperature range
-20 to +55 degrees Celsius
Stability
< +/- 4.00 ppm
Dimensions
W-3.4” x H-2.5” x D-4.7” (plus 1.5” for harness)
W-87mm xH-64mm x D-119mm (plus 35mm for
harness)
Weight
13.0 ounces
338 grams
FCC ID:
QNEM760REM
1.6
EQUIPMENT SUPPLIED
1 ea. of the following items:
Model
Description
Part Number
PAR100EX
PAR100EX Audio Panel with intercom and radio function control 050-760-0100
M760REM
VHF Communications Transceiver
050-760-6476
Installation Kit: 250-890-0000, containing:
Description
Quantity
Part Number
PAR100EX installation rack assembly
1
430-890-0040
PAR100EX Rack back plate
1
430-890-0050
44-pin connector kit
2
120-891-2045-
Backshell, connector
2
625-025-2465
Backshell Retainer
2
431-891-0100
4 40 X 7/16 screw w/nylon patch
4
475-440-0007
4 40 X 3/8 screw w/lock washer
4
475-440-1038
4 40 X 1/8 screw w/lock washer
2
475-440-0001
Solder Lug
2
475-009-0001
Cable Clamp
1
625-001-0002
#6-32 x ½” Flat head Philips screw
6
475-632-0012
#6-32 Clip Nut
6
475-630-0002
Installation Kit 250-760-6476, Containing:
Description
Quantity
Part Number
DB 15 Connector , Solder type
1
425-016-0001
DB 15 Connector back shell
1
425-015-0003
Ferrite RFI suppressor
1
507-000-0065
1.7
EQUIPMENT REQUIRED BUT NOT SUPPLIED
a.
Circuit Breaker: 1 ea; 3 amp PULL TYPE REQUIRED for PAR100EX
b.
Circuit Breaker: 1 ea; 3 amp PULL TYPE REQUIRED for transceiver power (to PAR100EX)
c.
Headphone Jacks (up to 4 Stereo, as Required)
d.
Microphone Jacks (up to 4 as Required)
e.
Headphones, 150 (Stereo), up to 4 as required
f.
Microphones, up to 4 as required
g.
VHF Communication antenna 118-137 MHz, VSWR <2:1 (FAA-TSO approved is recommended)
h.
BNC Connector for M760REM, Amphenol 31-2 or equivalent (PS PN 425-262-0312)
i.
Mounting hardware for M760REM, as appropriate
j.
Interconnect Wiring, coaxial cable
