PS Engineering Inc. ®
PAR100EX Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-760-0000 Page 2-14 Rev. 12, Jan. 2014
Figure 2-6 – PAR100EX DIP Switches
Figure 2-7 DIP switches
Change the settings as shown in the table below.
Switch Noisy Cockpit Normal Cockpit Switch Bank
Pilot Microphone
1 OFF ON
2 ON OFF
Copilot Microphone
3 OFF ON
J5
4 ON OFF
Passenger 1 Microphone
1 OFF ON
2 ON OFF
Passenger 2 Microphone
3 OFF ON
J4
4 ON OFF
Table 2-5 Microphone gain settings
1
2
3
4
5
6
ON OFF ON OFF
NOTE:
If top cover is removed
for ANY reason, you
MUST replace the cover
screws with the proper
length, otherwise damage
will result.
Shorter Screw
DIP Switches
