PAR100EX Audio Selector Panel and Intercom System
Installation and Operator’s Manual
200-760-0000
Page 2-19
Rev. 12, Jan. 2014
2.15 PAR100EX Pin assignments
J1
Function
J2
Function
1
No Connect
1
Pilot Phones Lo
2
No Connect
2
Copilot Phones Lo
3
No Connect
3
Copilot Phones (L)
4
No Connect
4
Copilot Phones (R)
5
No Connect
5
Lights lo
6
No Connect
6
12/28 V Lights
7
No Connect
7
12/28 V Lights
8
No Connect
8
Aircraft Power (12 VDC)
9
Com 1 Audio
9
Aircraft Power(12 VDC)
10
Com 1 Audio Lo
10
Aircraft Ground
11
Com 1 Mic
11
Aircraft Ground
12
Com 1 Mic Key
12
No Connect
13
Com 2 Audio
13
Music 2 Mute Inhibit
14
Com 2 Audio Lo
14
Music 2 Mute Inhibit Lo
15
Com 2 Mic
15
Unswitched #4
16
No connect
16
Pilot Phones (L)
17
Aux 1 Audio
17
RS232 RXD
18
Aux 1 Audio Lo
18
No connect
19
Aux 2 Audio
19
No connect
20
Aux 2 Audio Lo
20
Swap
21
No Connect
21
Swap Low
22
Unswitched #3 Lo
22
Music 1 All Headsets
23
No Connect
23
Music 1 (L)
24
No Connect
24
Music 1 (R)
25
No Connect
25
Music 1 Lo
26
No Connect
26
Music 2 (L)
27
No Connect
27
Music 2 (R)
28
No Connect
28
Music 2 Lo
29
Unswitched #3
29
RS232 TX
30
Com 2 Mic Key
30
+12 VDC Radio Out
31
Unswitched Audio 1
31
Pilot Phones (Rt)
32
Unswitched Lo
32
Copilot Mic Audio
33
Pilot Mic Audio
33
Copilot Mic PTT
34
Pilot Mic PTT
34
Copilot Mic Lo
35
Pilot Mic Lo
35
Pass 1 Mic Audio
36
No Connect
36
Pass 1 Mic Audio Lo
37
No Connect
37
Pass 2 Mic Audio
38
No Connect
38
Pass 2 Mic Audio Lo
39
No Connect
39
No Connect
40
Pass HP (L)
40
Unswitched #4 Lo
41
Pass HP (R)
41
No Connect
42
Pass HP Lo
42
+12 VDC Radio Lo
43
Unswitched 2 Lo
43
Radio Power Ground
44
Unswitched 2 Audio
44
Radio power
