MBOX
®
STUDIO USER MANUAL
141
Frame Blending
Values Description
0
No Frame Blending (more accurately, blend time = 0)
1-255
Variable Frame Blend Time, as a proportion of the
frame time. This is a square-law control, and 50%
blend time is achieved at value 210, 25% blend time
at value 165.
Video Input and Utility (Texture Folder 255)
Texture
Value
Input
0
Patch Info Display
121
Layer Copy FX+ Layer 1
122
Layer Copy FX+ Layer 2
123
Layer Copy FX+ Layer 3
124
Layer Copy FX+ Layer 4
125
Layer Copy FX+ Layer 5
126
Layer Copy FX+ Layer 6
127
Layer Copy FX+ Layer 7
128
Layer Copy FX+ Layer 8
201
Syphon Input 1
202
Syphon Input 2
203
Syphon Input 3
204
Syphon Input 4
240
CG Color bars
254
Video Input 2
255
Video Input 1
TC DMX Control
The TC DMX controls are only required when the TC
DMX Control feature has been configured. (Refer to
on page 78.) Each item in the TC DMX
Controls preference relates to one fixture that must be
patched to control timecode on a layer.
Chan
Size
Function
Default
Snap
1
1
Hours (0-23)
255
N
2
1
Minutes (0-59)
255
N
3
1
Seconds (0-59)
255
N
4
1
Frames (0-29)
255
N
DMX Layer Volume Control
When using DMX Layer Volume control, the layers don't
have to be controlled by the same universe, or using
consecutive addresses.
Chan
Size
Function
Default
Snap
1
1
Layer 1 volume
255
N
2
1
Layer 2 volume
255
N
3
1
Layer 3 volume
255
N
4
1
Layer 4 volume
255
N
5
1
Layer 5 volume
255
N
6
1
Layer 6 volume
255
N
7
1
Layer 7 volume
255
N
8
1
Layer 8 volume
255
N
9
1
Layer 9 volume
255
N
10
1
Layer 10 volume
255
N
11
1
Layer 11 volume
255
N
12
1
Layer 12 volume
255
N
