Special commands require that the parameter value be held
for three seconds, followed by an immediate change to
value 0 (without any other values in between).
**
Special command that requires the value to be held for
250mS, followed by an immediate change to 0 (with no val-
ues in between)
Note: Keystone, Warp, and Blend settings created in the
Mbox Remote application will override any Art-Net
controlled keystone values.
*
A Keystone Mode value of 0 enables the advanced projec-
tion mapping toolset that is accessed through the Mbox
Remote application. When the value is set to 0, if the
advanced projection mapping tools are being used, those
settings will override the standard corner controls.
**
Steep = Eighth Order, Medium = Fourth Order,
Shallow = Second Order
245
Disable Pixel Mapping Output *
246
Enable Masked Pixel Mapping fixtures *
247
Disable Masked Pixel Mapping fixtures *
250
Quit Mbox Application *
251
Shutdown Computer *
252
Restart Computer *
253
Restart Mbox Application *
Keystone
Chan
Size
Function
Default
Snap
1
1
0
Y
2
2
Keystone X
32767
N
4
2
Keystone Y
32767
N
6
2
Scale
65535
N
8
1
Edge 1 (top)
0
N
9
1
Edge 2 (left)
0
N
10
1
Edge 3 (bottom)
0
N
11
1
Edge 4 (right)
0
N
12
1
Corner 1-X
0
N
13
1
Corner 1-Y
0
N
14
1
Corner 2-X
0
N
15
1
Corner 2-Y
0
N
16
1
Corner 3-X
0
N
17
1
Corner 3-Y
0
N
18
1
Corner 4-X
0
N
19
1
Corner 4-Y
0
N
20
1
Keystone Rotation
127
N
Keystone Mode
Value
Mode
Blend
Curve
Grid
Overlay
Controls
0
Use
Mbox
Remote*
n/a
no
Keystone/
Warp is set
from Remote *
Master Control Channel (Continued)
Values
Command
1-8
Corners
Steep **
no
X/Y Corner
9
Steep
yes
10-18
Medium
no
19
Medium
yes
20-28
Shallow
no
29
Shallow
yes
30
Rotation
& Aspect
Steep
no
X/Y
Rotation &
Aspect
31
Medium
no
32
Shallow
no
39
Steep
yes
40
Rotation,
Aspect,
& Curve
Steep
no
X/Y Rotation,
aspect, &
X/Y Curve
41
Medium
no
42
Shallow
no
49
Steep
yes
Shutter
Chan
Size
Function
Default
Snap
1
1
0
Y
2
1
Red
0
N
3
1
Green
0
N
4
1
Blue
0
N
6
2
Scale
32767
N
7
1
Edge
0
N
8
1
Shutter 1a
0
N
9
1
Shutter 1b
0
N
10
1
Shutter 2a
0
N
11
1
Shutter 2b
0
N
12
1
Shutter 3a
0
N
13
1
Shutter 3b
0
N
14
1
Shutter 4a
0
N
15
1
Shutter 4b
0
N
Keystone Mode (Continued)
Value
Mode
Blend
Curve
Grid
Overlay
Controls
