MBOX
®
STUDIO USER MANUAL
139
Shutter Shape
Values
Shape
Notes
0-9
Disabled
10-19
Moving
Light Mode
Separate controls for each end of
shutter. If both controls are zero,
shutter disappears.
20-29
Leko Mode
Distance and angle controls. If
distance is zero, shutter disappears.
30-39
Iris Mode
A round iris, scale is magnified to
enclose the screen. No other controls.
40-49
Blob Mode
A Bezier curve is drawn touching the
midpoints of the rectangle formed by
Leko Mode.
Layer
Chan
Size
Function
Default
Snap
1
1
Effect 1
0
Y
2
1
Effect Control 1a
0
N
3
1
Effect Control 1b
0
N
4
1
Effect 2
0
Y
5
1
Effect Control 2a
0
N
6
1
Effect Control 2b
0
N
7
1
0
Y
8
1
0
Y
9
1
Red
255
N
10
1
Green
255
N
11
1
Blue
255
N
12
1
Opacity
0
N
13
1
Texture Folder
0
Y
14
1
Texture
0
Y
15
1
0
Y
16
1
Play Speed
127
N
17
2
In Frame
0
N
19
2
Out Frame
65535
N
21
1
0
Y
22
1
Sync Offset
0
N
23
1
255
N
24
1
Texture Xfade Type
0
Y
25
1
Texture Xfade Time
0
Y
26
2
X Position
32767
N
28
2
Y Position
32767
N
30
2
Scale
32767
N
32
2
X Scale
32767
N
34
2
Y Scale
32767
N
36
2
Z Rotation
32767
N
38
2
X Rotation
32767
N
40
2
Y Rotation
32767
N
42
1
Object
0
Y
43
1
Anim Control 1
0
N
Sync Stream
Values
Mode
0
Layer to Layer Stream (default)
1-8
Stream Number
Layer (Continued)
Chan
Size
Function
Default
Snap
