Make sure that the POWER switch of the I/O Box is set to OFF. Set the DIP switch of the
first I/O Box to be connected to the PC directly as follows.
1
2
3
4
5
6
7
8
9
10
ON
OFF
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Set the DIP switch of other I/O Boxes to be connected under daisy-chain as follows.
1
2
3
4
5
6
7
8
9
10
ON
OFF
OFF
OFF
ON
OFF
ON
ON
ON
ON
Set DIP switch no. 5 of the last I/O Box to ON if the C-OUT terminal does not connect another
I/O Box (This is for the termination).
5
ON
The above setup example assumes that the RS-232C baud rate is 115200 bps. If modifying this
setup, refer to the “With Single Satellite I/O Box” in the previous page.
Connect the first I/O Box and the PC with a cross-type RS-232C cable.
Then connect the C-OUT terminal of the I/O Box connected to the PC to the C-IN terminal of
the other I/O Box via the RS-422 cable. Connect the rest of I/O Boxes so that the one with the
terminator setting is the last under daisy-chain.
