Pilot 1200 manual.doc 2/20
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
FITTING THE LAMP 4
POWER SUPPLY – MAINS 5
CONTROL CONNECTIONS 5
DMX TERMINATOR 6
SETUP OPTIONS-PROJECTOR CONFIGURATION 6
TO SET THE DMX START ADDRESS 6
FUNCTIONS DISPLAY 7
ERRORS DISPLAY 9
REPLACING GOBOS 9
DMX CONTROL CHANNEL FUNCTIONS 10
LED DISPLAY 12
CHANGING BELTS 12
MAINTENANCE 13
LUBRICATION 13
KEEPING THE PROJECTOR CLEAN 13
TROUBLESHOOTING 13
TECHNICAL DATA 15
ELECTRICAL DIAGRAM 17
COMPONENT ORDER CODES 18
CHANGING THE OPERATION FREQUENCY 19
Please note that as part of our ongoing commitment to continuous product development, specifications are
subject to change without notice. Whilst every care is taken in the preparation of this manual we reserve the
right to change specifications in the course of product improvement. The publishers cannot be held responsible
for the accuracy of the information herein, or any consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or
the unit are in good condition before installation and use. Should there be any damage caused by transportation,
consult your dealer and do not use the unit. Any damage caused by improper use will not be assumed by the
manufacturer and / or dealer.
THESE ITEMS ARE PACKED TOGETHER WITH THE PROJECTOR
G clamps (2 PCS)
XLR cable with 3-pin plug and socket (1 PCS)
Safety cord (2 PCS)
Spare gobos (4 PCS)
This manual (1 PCS)
clamps(Options)(2PCS)
Thank you for purchasing our product PILOT 1200, PR-2900.
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future
reference.
PILOT 1200 is an innovative projector with an elegant housing, which complies to CE norms and
standards and uses international protocol DMX 512.
The projector uses HMI1200W/S discharge lamp and high quality optical system, which produces
bright and beautiful light beam and has 60% output lumen more than the similar products with the
same power consumption. The projector features effects of strobe, frost light, mixed colours and
rainbow, so it is suitable for applications in TV station, disc, singing and dancing stage, nightclub, etc.
ACCESSORIES
INDEX
INTRODUCTION
