The PILOT 1200 uses 22 DMX channels. They are listed in the following table.
CHANNEL DMX DESCRIPTION
000-009 Shuttering
010-024 White
025-039 Strobe 1(slowest)
040-054 Strobe 2
055-069 Strobe 3
070-084 Strobe 4
085-099 Strobe 5
100-114 Strobe 6
115-129 Strobe 7
130-144 Strobe 8
145-159 Strobe 9
160-174 Strobe 10
175-189 Strobe 11
190-204 Strobe 12
205-219 Strobe 13
220-234 Strobe 14
235-249 Strobe 15(fastest)
1
Strobe
250-255 White
000-024 White 2
Dimmer 025-255 Dimming from light to dark (0-100%)
3
Iris
000-255
Linearly adjust iris from large to small (0=wholly
open; 100=wholly closed)
000-031 White
032-063 Gobo 1
064-095 Gobo 2
096-127 Gobo 3
128-159 Gobo 4
160-167 Rotation speed 1 (slowest)
168-175 Rotation speed 2
176-183 Rotation speed 3
184-191 Rotation speed 4 (fastest)
192-223 Stop rotating
224-231 Reverse rotation speed 1 (slowest)
232-239 Reverse rotation speed 2
240-247 Reverse rotation speed 3
4
Fixed Gobo
248-255 Reverse rotation speed 4 (fastest)
5
Pan
000-255 Pan rotation
6
Tilt
000-255 Tilt rotation
7
Focus
000-255 Linearly focusing
8
Zoom
000-255 Zooming with spot from large to small
000-024
White. Note: stay 5 seconds while DMX value is 5, 6
or 7, the function reset perform
025-030 White/colour filter 1
031-036 Colour filter 1
037-042 Colour filter 1/colour filter 2
043-048 Colour filter 2
049-054 Colour filter 2/colour filter 3
055-060 Colour filter 3
061-065 Colour filter 3/colour filter 4
066-071 Colour filter 4
072-077 Colour filter 4/colour filter 5
9
Colour Wheel
078-083 Colour filter 5
DMX CONTROL CHANNEL FUNCTIONS
