Pilot 1200 manual.doc 11/20
084-089 Colour filter 5/colour filter 6
090-095 Colour filter 6
096-101 Colour filter 6/colour filter 7
102-107 Colour filter 7
108-113 Colour filter 7/white
114-121 Rotation speed 1 (fastest)
122-129 Rotation speed 2
130-137 Rotation speed 3
138-145 Rotation speed 4
146-153 Rotation speed 5
154-161 Rotation speed 6
162-169 Rotation speed 7
170-177 Rotation speed 8 (slowest)
178-191 Stop rotating
192-199 Reverse rotation speed 8 (slowest)
200-207 Reverse rotation speed 7
208-215 Reverse rotation speed 6
216-223 Reverse rotation speed 5
224-231 Reverse rotation speed 4
232-239 Reverse rotation speed 3
240-247 Reverse rotation speed 2
248-255 Reverse rotation speed 1 (fastest)
10
CYM-Cyan
000-255 Cyan (0-100%)
11
CYM-Yellow
000-255 Yellow (0-100%)
12
CYM-Magenta
000-255 Magenta (0-100%)
000-050 White
051-101 Gobo 1
102-152 Gobo 2
153-203 Gobo 3
13
Rotating Gobo
204-255 Gobo 4
000-119 Gobo index 0~540
120-127 Rotation speed 1 (fastest)
128-135 Rotation speed 2
136-143 Rotation speed 3
144-151 Rotation speed 4
152-159 Rotation speed 5
160-167 Rotation speed 6
168-175 Rotation speed 7
176-183 Rotation speed 8 (slowest)
184-191 Stop rotating
192-199 Reverse rotation speed 8 (slowest)
200-207 Reverse rotation speed 7
208-215 Reverse rotation speed 6
216-223 Reverse rotation speed 5
224-231 Reverse rotation speed 4
232-239 Reverse rotation speed 3
240-247 Reverse rotation speed 2
14
Gobo Rotation
248-255 Reverse rotation speed 1 (fastest)
000-050 White
051-101 Prism 1
102-152 Prism 2
153-203 Prism 3
15
Prism
204-255 Prism 4
000-119 Index 0~540
120-127 Rotation speed 1 (fastest)
128-135 Rotation speed 2
136-143 Rotation speed 3
16
Prism Rotation
144-151 Rotation speed 4
