OmniSistem OnyxPro 40 User Manual

Page 16

Mode

Addr

XXX

DMX Address Setting

Slav

Choose Slave Mode

Sequ

Alon/Mast

Choose Sequence
Mode

Sund

Alon/Mast

Choose Sound Mode

Lamp

Temp

80~139°C, 90°C

Set internal
temperature to shut the
unit off. (Activates after
5 minutes.)

Adju

CHXX=XXX

Adjust Value of Each
Channel

Info

DriT

XXXC

Driver Temperature

Set

Rest

Reset

Move

RPan                ON/OFF
RTilt                  ON/OFF
Degr                 630/540
Enco                 ON/OFF
Mode                Mod1/Mod2

Reverse Pan
Reverse Tilt
Choose Pan Degree
Encoder Wheel
Choose Pan/Tilt Mode

Mic                    0~99%, 60%
Sign                  Close/Hold/Auto/Music
Fan                   Auto Speed/High Speed
Hibe                  OFF, 01M~99M, 15M
Back                 02~60M, 02M
Flip                   ON/OFF
User                  Use1/Use2

Mic Sensitivity
Signal Mode
Fan Mode
Hibernate Time
Backlight Time
Flip Display 180°
DMX Mode (St/Ex)

Cali

Code XXX
CHXX XXX

Password (050)
Calibrate Channel

Ver

X1.0.0

IC Version

load

ON/OFF

Reload Default

RDM

With this function you can call up various submenus via RDM.

This device is RDM ready. RDM stands for "Remote Device Management" and makes remote control of devices
connected to the DMX bus possible. ANSI E1.202006 by ESTA specifies the RDM standard as an extension of
the DMX512 protocol.

Manual settings like adjusting the DMX starting address are no longer needed. This is especially useful when the
device is installed in a remote area.

RDM is integrated in DMX without influencing the connections. The RDM data is transmitted via the standard XLR
poles 1 and 2 — new DMX cables are not necessary. RDM ready and conventional DMX devices can be operated
in one DMX line. The RDM protocol sends its own packages in the DMX512 data feed and does not influence
