Attach wood handle to smoker chamber door using two
1/4-20x3” screws, flat washers, handle spacers and 1/4-20 flange
nuts, as shown below. Repeat to attach handle to firebox door.
NOTE: Smoker chamber door not pictured for clarity.
Install grate support screws in the
four rear holes and two
front-center holes in the smoker chamber. Use six #10-24x1”
screws and #10 flange nuts.
Smoker chamber
door
Handle spacer
Handle
