Attach leg braces to the outside of one leg assembly using
#10-24x1¾” screws and #10-24 flange nuts. Make sure slotted
(oval) hole is toward bottom of leg.
Do not fully tighten screws until Step 8 is complete.
2
1
FIRST, GET A HELPER! This unit is heavy and requires a second person for lifting and moving. NEXT, pick a suitable location to
work. Open the carton and slit the corners so that the carton lays flat. This will give you a protective work surface during assembly.
TO BEGIN ASSEMBLY, build two leg assemblies by sliding the long leg sections into the short leg sections.
Long leg section
Leg brace
Short leg section
Slotted
hole
Leg brace
