6
4.3 UC5-CAB-HG06-HG07 – HG06/HG07 Cab Kit Parts List (Hagie
Kit Number – 693756)
Item NORAC Part Number Hagie Part Number Name Quantity
C01 43260-13 693142 CABLE UC5 NETWORK HAGIE STS CAB TO BULKHEAD 1
C30 43250-19 693746 CABLE UC5 BATTERY 4-PIN DT FUSED (ECU & SIG) 1
E01 43710 693139 UC5 CONTROLLER MODULE 1
4.4 UC5-BOOM-HG07 – HG07 Boom Kit Parts List (Hagie Kit
Number – 693754)
Item NORAC Part Number Hagie Part Number Name Quantity
B10 44728 693068 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
B11 44743 693072 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B12 44695-11 693069 MOUNTING BRACKET BREAKAWAY ADAPTER UC3 SENSOR NITRO/HAGIE 2
C03 43260-26 693078 CABLE UC5 NETWORK HAGIE 12 PIN DT (B-KEY) TO 6 PIN DT - 90" 1
C04 43260-12 693135 CABLE UC5 NETWORK HAGIE STS BOOM DISCONNECT TO 8-WAY 1
C05 43220-01 693741 CABLE UC5 NETWORK 14 AWG 1M 2
C06 43220-05 693161 CABLE UC5 NETWORK 14 AWG 5M 1
C07 43210-10 693145 CABLE UC5 NETWORK 18 AWG 10M 2
C08 43220-07 693162 CABLE UC5 NETWORK 14 AWG 7M 2
C09 43260-27 693077 CABLE UC5 NETWORK HAGIE 12 PIN DT (B-KEY) TO 6 PIN DT - 10" 1
E04 43741 693165 UC5 ROLL SENSOR VER. 2 2
E05 43750 693113 UC5 ULTRASONIC SENSOR 3
E10 43760 693147 UC5 NETWORK COUPLER 3-WAY 3
E11 43765 693131 UC5 NETWORK COUPLER 8-WAY 1
E12 43764 693128 UC5 NETWORK COUPLER 2-WAY 1
E20 43764T 693146 UC5 NETWORK COUPLER 2-WAY WITH TERMINATOR 2
M02 UC5-BC-HG07-INST 693742 MANUAL INSTALLATION UC5 HAGIE (STS 2014+) 1
M05 106562 693743 SCREW MACH HEX SS 6-32X1/2 IN 4
P03 105882 693800 UC5 NETWORK 6 PIN PLUG 5
