28 M12 160x120 Thermal Imager Operator’s Manual
infrared (IR) Electromagnetic energy in wavelengths that are between visible light and RF (radio
frequency).
infrared detector A transducer element (sensor) that converts incoming radiant infrared energy striking its
surface into an electrical signal. The Thermal Imager measures this signal and translates it
into a thermal image (Also see “bolometer.”)
IP rating An international standard rating system for a device’s resistance to water and dust
JPEG (.jpg) A file format used for digital photographs.
LCD Liquid-Crystal Display -- the type of color display on the Thermal Imager.
LED Light-Emitting Diode – used as light-up indicators
LED floodlight A floodlight to illuminate the work area. It helps with the visual images, but does not change
thermal images.
lens cap A protective cover over the thermal imager lens.
level The mid-way temperature point of the range in use. When you adjust the level, the width of the
window from lowest to highest temperature stays the same and the whole window moves up
or down in temperature.
Li-Ion Lithium-Ion: the type of rechargeable battery used in the MILWAUKEE M12 series products.
load The term for transferring images to a computer. You can load images directly from the SD card
using the SD card reader USB adapter, or from the Thermal Imager with the SD card installed,
using the USB cable.
M12 A family of MILWAUKEE 12V Li-Ion rechargeable battery powered tools, rechargeable
batteries and accessories.
media door The rubber cover over the SD card slot and Mini USB socket on the side of the Thermal
Imager.
