Petaluma (MAXREFDES30#) ZedBoard Quick Start Guide
6
4. Procedure
1. Install a 2-pin header on the J18 connector on the ZedBoard if the 3V3 header is
missing.
2. Remove any shunt on 1V8 and 2V5 headers, and install a shunt on the 3V3
header.
3. Connect the Petaluma board to the J1 FMC connector of the ZedBoard as shown
in Figure 1 .
4. Power up the ZedBoard by sliding the SW8 switch on the ZedBoard to the ON
position.
5. Download the latest RD30V01_00.ZIP file at
www.maximintegrated.com/Petaluma . All files available for download are
available at the bottom of the page.
6. Extract the RD30V01_00.ZIP file to a directory on your PC. The location is
arbitrary but the maximum path length limitation in Windows (260 characters)
should not be exceeded.
In addition, the Xilinx tools require the path to not contain any spaces.
C:\Do Not Use Spaces In The Path\RD30V01_00.ZIP
(This path has spaces.)
For the purposes of this document, it will be C:\designs\maxim\RD30V01_00\.
See
Appendix A: Project Structure and Key Filenames in this document for
the project structure and key filenames.
