Malone MPG460XT User Manual
Page 6
MPG460XT
800-295-0042 ext 206
6
5. Install the clip nut as
shown on the end of the
short piece of 2x3 tub-
ing. Note, the parts are
symetrical so it doesn’t
matter which way they
are turned. Then fi t the
rear tongue support
bracket over the clip nut
and install a short bolt
and washer. Hand tight
only. Now fl ip the rear
tongue support assembly
over so the bolt head on the bottom.
6. Slide the rear tongue support assembly, bolt head down, in between
the frame rails as shown.
7. Set the retractable tongue box onto the frame as shown.
