800-295-0042 ext 206

MPG460XT

10. Tighten the lug fi rmly to 75 to 85
foot pounds of torque.

11. Slip the large U-bolt in place
over the retractable tongue assembly
as shown. Install the 2 hole frame
strap under the assembly and install
the 1/2” nuts.

Turn the U-bolt at an angle as shown
so its legs are against the tubes.
Fully tighten the 2 nuts.

Now tighten the bolt in the center of
the rear tongue support.

12. Install the 2” x 3” plastic hole plug
into the end of the frame as shown. Use
your hammer to tap it in.
