MPG460XT
FENDER ASSEMBLY (Group 4)
1. Connect all 4 fender brackets to the fenders using 3/8” x 3/4” slot head
screws and nuts. Assemble with the nuts
to the inside of the fenders as shown. No
washers here. Fully tighten all 8 screws
and nuts.
Note: fenders are
symmetrical and fi t on
either side of the trailer.
