15. Install the wiring harness extension
thru the tongue. The easiest way is to let
gravity pull the harness through. Make a
fold in the harness near the end with the
white ground wire. Push the fold into a
heavy socket (or tape any heavy object to
the fold). Feed the weight into the tongue
and let gravity pull the harness through.
Remove the weight. Tuck the ends of the harness just inside the tongue.
13. Attach the rubber stand-up feet
to the rear of the frame as shown.
14. Attach the retractable tongue retainer bracket to
the inside of the rear frame crossmember as shown.
16. Slide the tongue (end without the white wire) into the retractable receiver box until the hole in
the box aligns with one of the 2 holes in the sides of the
tongue. Pass the hitch pin through and install the ring
clip.
