Enhanced 10/100Base-TX to 100Base-FX Converter
- 19 -
port on the Converter and the other end to the
ST/SC/WDM port on the other device.
Note: When inserting the cable, be sure the tab on the plug
clicks into position to ensure that it is properly seated.
5. Use DIP switch 4 to select between half and full
duplex modes for the fiber port
6. Check the corresponding port LED on the
Converter to make sure that the connection is
valid. (Refer to the LED chart in next section)
Connecting Copper Cable
The 10/100BASE-TX RJ-45 Ethernet port fully
supports auto-sensing and auto-negotiation.
1. Insert one end of a Category 3/4/5/5e type twisted
pair cable into an available RJ-45 port on the
Converter and the other end into the port of the
network node.
2. Check the corresponding port LED on the
Converter to be sure that the connection is valid.
(Refer to LED chart in next section)
Enhanced 10/100Base-TX to 100Base-FX Converter
- 20 -
4 LED Indicators
This Converter has LED indicators located at the front
of the device. The LEDs have been designed to give
easy at-a-glance network status, and provides ‘real-
time ’ connectivity information. Please see below for an
interpretation of their functions:
Unit LEDs
LED Condition Status
On (Green)
Converter is
receiving power
PWR
Off
Power off or
failure
On (Red)
Disruption of
connection in
copper/fiber
segment
LFS
Off
Copper/fiber
segment is ‘OK’
