Enhanced 10/100Base-TX to 100Base-FX Converter
- 15 -
Install the converter
This Converter utilizes ports with fiber and copper port
connectors functioning under Ethernet and/or Fast
Ethernet protocols.
10/100BASE-TX Port
The 10/100BASE-TX port supports network speeds of
either 10Mbps or 100Mbps, and can operate in half-
and full duplex transfer modes. This port also offers
automatic MDI/MDI-X crossover detection that gives
true "plug and play" capability - just plug-in the
network cable to the port and the port will adjust
according to end node device automatically. The RJ-
45 connector is suitable for UTP cable Category 3, 4,
5 or better.
100BASE-FX Port
The 100BASE-FX port adds a fiber Fast Ethernet link
to your network device. Compliant with IEEE 802.3u,
this port can transmits data at 100Mbps in full duplex
mode across distances of up to 2km over multi-mode
fiber-optic cable. The fiber port has a choice of three
fiber connector types: ST, SC and WDM.
Enhanced 10/100Base-TX to 100Base-FX Converter
- 16 -
Desktop Installation
Follow the instructions listed below to install the
Converter onto a desktop location.
1. Locate the Converter in a clean, flat and safe
position that has easy access to AC power.
2. Affix the four (4) self-adhesive rubber pads to the
underside of the Converter.
3. Apply AC power to the Converter. (The green PWR
LED on the front panel should light).
4. Connect cables from the network partner devices
to the ports on the front panel. (The green LNK
LED on the front panel associated with the port
should light).
This Converter can also be mounted on a vertical
surface. Simply use the underside of the unit as a
template to measure and mark out the position of the
holes on to the surface where the unit is to be installed.
Then use two screws to mount the converter firmly in
place.
