Prior to Operation
The leveling system should only be operated under the following conditions:
1. The coach is parked on a reasonably level surface.
2. The coach “PARKING BRAKE” is engaged.
3. The coach transmission should be in the neutral or park position.
4. The ignition is in the run position, or engine is running.
5. Be sure all persons, pets and property are clear of the coach while Lippert Leveling System is in
operation.
Operation
Selecting A Site
When the coach is parked on an excessive slope, the leveling requirements may exceed the jack lift stroke
capability. If the coach is parked on an excessive slope, the coach should be moved to a more level surface before
the leveling system is deployed.
Automatic Leveling Procedure
NOTES:
• Refer to (Fig. 5) for questions regarding location and functions of the Lippert Components Inc.
Electronic/Hydraulic Leveling System.
• Coach must be running for LCI Electronic/Hydraulic Leveling System to operate.
1. Push ON/OFF button on Control Panel. The system is now operational and the electronic level lights
will become active.
2. Check to see that the Control Pad ENGAGE PARK BRAKE light is not flashing.
NOTE: Engage Parking Brake if ENGAGE PARK BRAKE light is flashing.
3. Push the AUTO button to begin the automatic leveling cycle.
NOTE: After starting the automatic leveling cycle it is very important that you do not move around in the
coach until the unit is level and the green LCI logo light illuminates in the center of the touch pad.
Failure to remain still during the leveling cycle could have an affect on the performance of the
leveling system.
4. If further adjustments are necessary, simply push and hold the MAN button (Fig. 5A) for approximately
5 seconds until the light under this button is illuminated. Push the appropriate leg button to override
the system and level the coach to your liking.
NEVER LIFT ALL THE WHEELS OFF THE GROUND TO LEVEL THE COACH!
Lifting all wheels off the ground may result in death or serious personal injury.
5. Push ON/OFF button to de-energize the system.
