Air and Auxiliary Feature Configuration
For Diesel Units with Airbag Suspensions ONLY:
• Feature is entered ONLY after zero mode programming.
• At this point the WAIT LED (Fig. 5E) will blink for 20 seconds. You are now in Air/Auxiliary Feature
Configuration mode.
To enable Air Auxiliary features, perform the following:
• Press the RETRACT ALL (Fig. 5P) switch 3 times.
• User must do this within 20 seconds of entering this mode.
To disable Air features, perform the following:
• Do nothing.
• After 20 seconds, module will exit mode with features disabled.
Error Mode
If any problem is detected with the jacks, the system will enter error mode. Error mode may be recognized by the
blinking of LEFT, LEVEL and RIGHT LEDs.
The following errors are detected by this system:
• Jack over current/short circuit.
• Jack under current/ open circuit.
• Jack extending too long (ground not detected after 2 min).
• Jack retracting too long (fully retracted not detected after 2 min).
• Out of stroke detection during auto cycle (if enabled).
User Alarm Mode
If the alarm system detects that the park brake has been disengaged while at least one jack is not fully retracted and
the sensor value changes in any axis more than a predefined amount, the panel will signal this error to the user.
When in alarm mode, all LEDs will flash and the buzzer will beep. The Status LEDs will show the system status.
The system will perform an automatic retract.
No other features are available in this mode.
Miscellaneous
• The system will automatically shut down after 4 minutes of no operation.
• Auto leveling cycle cannot be started until all jacks are fully retracted. Make sure jacks are retracted
before attempting to auto level (unit will perform full retract automatically if jacks are not down on
the request of an auto cycle).
• System will refuse any operation when a low voltage condition is present.
• System will automatically alarm and retract if park brake is disengaged and jacks are not retracted
with any change in sensor readings. In alarm mode, the only available feature is to retract all jacks.
• Please note the Wait LED shows the status of Air/ Auxiliary features.
• Please note that the LEDs blink differently when in special controller modes (error, alarm, and
configuration). Learning how to recognize these modes is important. Excess slope LED blinks
whenever the Y axis (vehicle length) is over 5 o from programmed level point.
