ENGLISH
Chapter 5: KGUARD Web Client
DVR User’s Manual
95
7
Modify the necessary settings:
Menu item Description
Sensitivity Select the motion detection sensitivity rate. Options are : 1~8, wherein “8” is the
most sensitive and “1” is the least sensitive.
Buzzer Set the buzzer duration when motion is detected (Off/10 S/20 S/40 S/60 S).
To disable buzzer, select Off.
Full Screen Check the box to enable this function. If this function is enabled and the alarm is
triggered, the corresponding channel will be displayed in full screen.
Enable Record Check the box to enable recording when the motion is detected.
Post Recording Select the post recording duration. Enable Record must be checked to use this
function.
Record Channel Check the box of Enable Record and then select the channels to record when the
motion is detected.
Show Message Check the box to display a message on screen when the alarm is triggered.
Send Email Check to enable email alarm notification. If the function is enabled, the system will
send the alarm images to the specified email address.
8
To save the settings, click Apply at the bottom of the screen.
When motion detection is enabled on a channel, the motion detection icon M appears on the channel screen shown
on the monitor connected to the DVR.
Setting the Alarm Notification (16-Channel only)
1
On the Main Menu, click Remote Setting.
2
On the left panel, click Alarm > Alarm. The Alarm screen appears.
3
Modify the necessary settings:
Menu item Description
Alarm In Select the channel that will trigger the alarm.
Alarm Type Select the alarm type: NO (Normal-Open), NC (Normal-Close), or OFF.
Buzzer Set the buzzer duration when alarm is triggered (Off/10 S/20 S/40 S/60 S).
To disable the buzzer, select Off.
Dwell Time Select the alarm sound duration of the I/O alarm device (10S/20S/40S/60S) then check
to apply the setting to each alarm type.
Show Message Check the box to display a message on screen when the alarm is triggered.
