ENGLISH
Chapter 4: Using the DVR
DVR User’s Manual
41
4.1.2 Output Settings
1
In the preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu > DISPLAY, then select the Output tab.
3
Modify the necessary settings:
Menu item Description
Video Output To set the video output setting of the main monitor used for live view display.
View Setup Select Enable to enable view setup.
Note:
When View Setup is enabled, Split Windows function is not available (see “3.5.2
Split Mode” on page 35 ).
View Mode Select how you want to split the windows, options are: Single, Quad, Nine, Sixteen.
Note:
Sixteen option is only available on 16-channel model.
Define SEQ setting Click Define SEQ setting to set the order of how the channels appear.
VGA/HDMI
Resolution
Select the output resolution.
Init. DEV
(Initial Device) Select where you want to display the OSD menu (BNC Video Out, HDMI, or Auto
Detection).
Transparency Slide the bar to adjust the transparency of windows.
4
After all settings are complete, click Apply.
5
When data saving is complete, click OK.
