Optical signals:
The triangle above the "+" - or the "-" symbol indicates whether the sample weighed
is within the tolerance range:
Goods to be weighed above tolerance limit
Goods to be weighed within tolerance range
Goods to be weighed below tolerance limit
Traffic light function:
The indicator lights up in red, green and orange, depending on the area in which your
sample is:
red Goods to be weighed above tolerance limit
green Goods to be weighed within tolerance range
orange Goods to be weighed below tolerance limit
Weighing with tolerance range
 Tare when using a weighing container
 Put on goods to be weighed, tolerance control is started
Load below specified
tolerance Load within specified
tolerance Load exceeds specified
tolerance
orange background green background red background
