74
5-6 Attaching the Shoulder Strap
To detach the shoulder strap, first open the hooks, then detach
the strap.
Make sure that the shoulder strap is securely attached.
5-7 Attaching the Rain Cover
When using the SHAN-RC700 Rain Cover
5-8 Connecting the AJ-EC3E
Extension Controller
Some functions can be remote-controlled when the AJ-EC3E
extension control unit (optional) is connected to the camera.
When the AJ-EC3E is connected, the camera automatically
enters remote control mode after the power switches of both the
camera and the AJ-EC3E are turned ON.
z Be sure to turn OFF both the camera and the AJ-EC3E power
switches before connecting or disconnecting the controller
cable.
z If ECU DATA SAVE is set to OFF, the camera-related setting
values, which have been adjusted or set using the AJ-EC3E,
will be canceled when the camera power switch is turned OFF.
Also, the setting values cannot be written to an SD card.
However, the menu settings performed using the AJ-EC3E
can be written to an SD card. Next time the AJ-EC3E is
connected, the setting values will return to the AJ-EC3E
settings.
ECU DATA SAVE can be selected from the
screen on the CAM OPERATION page.
z If ECU DATA SAVE is set to ON, the values adjusted or set
using the AJ-EC3E are retained, even after the camera power
switch is turned OFF.
z The USER switch on the camera does not function when the
AJ-EC3E is connected.
z When controlling the shutter from the AJ-EC3E, the shutter
speeds correspond to the speeds set by the menu on the
camera, not the speeds written on the AJ-EC3E. The shutter
speeds correspond as follows:
Press to open
the hook.
Shoulder Strap
Tighten the cord
Secure with the
surface fastener
Secure with the surface fastener
AJ-EC3E
Shutter Speed Indication
Camera Shutter Speeds
100 (60) POSITION1
120 POSITION2
250 POSITION3
500 POSITION4
1000 POSITION5
2000 POSITION6
AJ-
w
Controller Cable
ECU Connector
AJ-EC3E
