background image

15

PARTS LIST

Key Qty Description

A

1

FIREBOX

B

1

IGNITOR

C

1

BURNER

D

1

COLLECTOR/ ELECTRODE ASSY

E

1

LID

F

1

LOGO PLATE

G

1

LEFT SIDE SHELF F/ SB

H

1

RIGHT SIDE SHELF

I

1

TANK RETAINER

J

1

MOUNTING BRACKET, F/ SIDE SHELF,
(RF/LB)

K

1

MOUNTING BRACKET, F/ SIDE SHELF,
(LF/RB)

L

1

MOUNTING BRACKET, F/ PLASTIC SIDE
SHELF, BACK

M

1

MOUNTING BRACKET, F/ PLASTIC SIDE
SHELF, FRONT

N

2

CART LEG,UPPER

O

1

SIDE BRACE

P

1

RIGHT FRONT LEG,CURVED

Q

1

RIGHT BACK LEG,STRAIGHT

R

1

LEFT BACK LEG,STRAIGHT

S

1

LEFT FRONT LEG,CURVED

T

2

BACK BRACE

U

2

SUPPORT BRACKET

V

1

LEFT FIREBOX SUPPORT

W

1

RIGHT FIREBOX SUPPORT

X

1

VALVE HOSE REGULATOR ASSEMBLY

Y

1

CONTROL PANEL

Z

1

FRONT PANEL

AA

1

CONDIMENT BASKET

BB

1

AXLE ROD

CC

2

LEG EXTENDER

DD

3

TANK EXCLUSION WIRE

EE

1

HEAT SHIELD

FF

1

COOKING GRATE

GG

1

SWINGAWAY GRID

HH

1

SIDEBURNER GRATE

II

1

SIDEBURNER

JJ

1

ELECTRODE, F/ SB

KK

1

DRIP PAN

LL

2

WHEEL

Key Qty Description

MM

3

KNOB

NN

2

LOWER HINGE

OO

2

UPPER HINGE

PP

1

HANDLE

QQ

1

GREASE CUP

RR

1

GREASE CUP CLIP

SS

1

HEAT TENT

TT

1

MATCH HOLDER

…

1

HARDWARE PACK

…

1

ASSY INSTRUCTIONS, ENGLISH

…

1

ASSY INSTRUCTIONS, FRENCH

…

1

RETAINER CLIP

NOT Pictured
