REPLACEMENT PARTS FOR OCC AND WCC CONTROL CENTER (cont’d.)
Qty. Description Part Number
OCC or WCC-15-413, 480V, 1-3ø, 10 & 12 kW
1 Circuit Breaker, 480V, 20 Amp, 3 pole........................104-071818-018
1 Contactor, 600V, 20 Amp, 3 pole................................072-120812-005
2 Fuses, FNQ 1/2 (F1 and F2)........................................128-114696-010
1 Transformer, 150VA....................................................315-048507-018
OCC or WCC-15-423, 480V, 2-3ø, 20 & 24 kW
1 Circuit Breaker, 480V, 40 Amp, 3 pole........................104-071818-022
2 Contactors, 600V, 20 Amp, 3 pole..............................072-120812-005
2 Fuses, FNQ 6/10 (F1 and F2)......................................128-114696-005
6 Fuses, KTK-20 (F3 thru F8) ........................................128-047763-003
1 Transformer, 150VA....................................................315-048507-018
1 Time Delay Relay........................................................311-115540-001
OCC or WCC-10-433, 480V, 3-3ø, 30 kW
1 Circuit Breaker, 480V, 50 Amp, 3 pole........................104-071818-024
3 Contactors, 600V, 20 Amp, 3 pole ............................ 072-120812-005
9 Fuses, KTK-20 (F3 thru F11) ......................................128-047763-002
1 Transformer, 250VA....................................................315-048507-024
2 Time Delay Relay........................................................311-115540-001
2 Fuses, FNQ 6/10 (F1 and F2)......................................128-114696-005
Qty. Description Part Number
OCC or WCC-25-233, 240V, 3-3ø, 30 kW
1 Circuit Breaker, 240V, 100 Amp, 3 pole......................104-071818-014
3 Contactors, 600V, 30 Amp, 3 pole ............................072-120812-005
9 Fuses, KTK-30 (F3 thru F11) ......................................128-047763-005
1 Transformer, 250VA....................................................315-048507-024
2 Time Delay Relay........................................................311-115540-001
2 Fuses, FNM 1- 4/10 (F1 and F2).................................128-114696-013
OCC or WCC-25-413, 480V, 1-3ø, 18 kW
1 Circuit Breaker, 480V, 30 Amp, 3 pole........................104-071818-020
1 Contactor, 600V, 30 Amp, 3 pole................................072-120812-001
2 Fuses, FNQ V2 (F1 and F2).........................................128-114696-010
1 Transformer, 150VA....................................................315-048507-018
OCC or WCC-25-423, 480V, 2-3ø, 36 kW
1 Circuit Breaker, 480V, 60 Amp, 3 pole........................104-071818-025
2 Contactors, 600V, 30 Amp, 3 pole..............................072-120812-001
2 Fuses, FNQ 4/10 (F1 and F2)......................................128-114696-010
6 Fuses, FRS-35 (F3 thru F8) ........................................128-121133-063
1 Transformer, 150VA ...................................................315-048507-018
1 Time Delay Relay........................................................311-115540-001
OCC or WCC-15-433, 480V, 3-3ø, 36 kW
1 Circuit Breaker, 480V, 70 Amp, 3 pole........................104-071818-026
3 Contactors, 600V, 20 Amp, 3 pole..............................072-120812-005
9 Fuses, KTK-20 (F3 thru F11) ......................................128-047763-003
1 Transformer, 250VA....................................................315-048507-024
2 Time Delay Relay .......................................................311-115540-001
2 Fuses, FNQ 6/10 (F1 and F2)......................................128-114696-005
OCC or WCC-30-213, 240V, 1-3ø, 12 kW
1 Circuit Breaker, 240V, 40 Amp, 3 pole .......................104-071818-007
1 Contactor, 600V, 30 Amp, 3 pole............................... 072-120812-005
2 Fuses, FNQ 8/10 (F1 and F2)......................................128-114696-011
1 Transformer, 150VA....................................................315-048507-018
OCC or WCC-20-413, 480V, 1-3ø, 15 kW
1 Circuit Breaker, 600V, 25 Amp, 3 pole........................104-071818-019
1 Contactor, 600V, 20 Amp, 3 pole................................072-120812-005
2 Fuses, FNQ V2 (F1 and F2).........................................128-114696-010
1 Transformer, 150VA....................................................315-048507-018
OCC or WCC-30-223, 240V, 2-3ø, 24 kW
1 Circuit Breaker, 240V, 80 Amp, 3 pole........................104-071818-012
2 Contactors, 600V, 30 Amp, 3 pole..............................072-120812-001
2 Fuses, FNM 8/10 (F1 and F2) .....................................128-114696-012
6 Fuses, FRN (F3 thru F8) .............................................128-121133-077
1 Time Delay Relay........................................................311-115540-001
1 Transformer, 150VA....................................................315-048507-018
OCC or WCC-20-423, 480V, 2-3ø, 30 kW
1 Circuit Breaker, 480V, 50 Amp, 3 pole........................104-071818-024
2 Contactors, 600V, 20 Amp, 3 pole..............................072-120812-005
2 Fuses, FNQ 6/10 (F1 and F2)......................................128-114696-005
6 Fuses, KTK-25 (F3 thru F8) ........................................128-047763-004
1 Transformer, 150VA....................................................315-048507-018
1 Time Delay Relay .......................................................311-115540-001
OCC or WCC-30-233, 240V, 3-3ø, 36 kW
1 Circuit Breaker, 600V, 125 Amp, 3 pole......................104-071818-045
3 Contactor, 600V, 30 Amp, 3 pole................................072-120812-005
9 Fuses, FRN 40 (F3 thru F11) ......................................128-121133-077
1 Transformer, 250VA....................................................315-048507-024
2 Relays, Time Delay .....................................................311-115540-001
2 Fuses, FNM 1- 4/10 (F1 and F2).................................128-114696-013
OCC or WCC-20-433, 480V, 3-3ø, 45 kW
1 Circuit Breaker, 480V, 70 Amp, 3 pole........................104-071818-026
3 Contactors, 600V, 20 Amp, 3 pole..............................072-120812-005
9 Fuses, KTK-25 (F3 thru F11) ......................................128-047763-004
1 Transformer, 250VA....................................................315-048507-024
2 Time Delay Relay .......................................................311-115540-001
2 Fuses, FNQ 6110 (F1 and F2).....................................128-114696-005
OCC or WCC-30-413, 480V, 1-3ø, 21 & 24 kW
1 Circuit Breaker, 480V, 40 Amp, 3 pole........................104-071818-022
1 Contactor, 600V, 30 Amp, 3 pole................................072-120812-001
2 Fuses, FNQ V2 (F1 and F2).........................................128-114696-010
OCC or WCC-25-213, 240V, 1-3ø, 3 & 8 & 10 kW
1 Circuit Breaker, 240V, 30 Amp, 3 pole........................104-071818-005
1 Contactor, 600V, 30 Amp, 3 pole................................072-120812-005
2 Fuses, FNQ 8/10 (F1 and F2)......................................128-114696-011
1 Transformer, 150VA....................................................315-048507-018
OCC or WCC-30-423, 480V, 2-3ø, 42 kW
1 Circuit Breaker, 480V, 70 Amp, 3 pole .......................104-071818-026
2 Contactor, 600V, 30 Amp, 3 pole................................072-120812-001
2 Fuses, FNQ 4/10 (F1 and F2)......................................128-114696-010
6 Fuses, FRS-40 (F3 thru F8) ........................................128-121133-064
1 Transformer, 150VA....................................................315-048507-018
1 Time Delay Relay....................................................... 311-115540-001
OCC or WCC-25-223, 240V, 2-3ø, 16 & 20 kW
1 Circuit Breaker, 240V, 70 Amp, 3 pole........................104-071818-011
2 Contactors, 600V, 30 Amp, 3 pole..............................072-120812-001
2 Fuses, FNM 8/10 (F1 and F2) .....................................128-114696-012
6 Fuses, KTK-30 (F3 thru F8) ....................................... 128-047763-005
1 Transformer, 150VA....................................................315-048507-018
1 Time Delay Relay........................................................311-115540-001
OCC or WCC-30-423, 480V, 2-3ø, 48 kW
1 Circuit Breaker, 480V, 80 Amp, 3 pole........................104-071818-027
2 Contactors, 600V, 30 Amp, 3 pole..............................072-120812-001
2 Fuses, FNQ 4/10 (F1 and F2)......................................128-114696-010
6 Fuses, FRS-45 (F3 thru F8) ........................................128-121133-065
1 Transformer, 150VA....................................................315-048507-018
1 Time Delay Relay........................................................311-115540-001
