Chromalox TUFF-TUBE PD437-4 User Manual

Chromalox, Installation, operation, Maintenance instructions

background image

Chromalox

®

DIVISION

4

SECTION

TPR/TPF

SALES

REFERENCE

DATE

SERVICE REFERENCE

Installation, Operation

and

Maintenance Instructions

PD437-4

161-074306-001

SEPTEMBER, 1998

(Supersedes PD437-3)

© 2010 Chromalox, Inc.

Tuff-Tube

One and Tuff-Tube

Three

PFA Teflon

®

Thermoplastic Covered Metal Sheath

Over-the-Side Immersion Heater

TUFF-TUBE

ONE (TPR)

Dimensions (In.)

Model

Watts

Volts

Phase

A

B*

C**

D

TPR-101

1000

120

1

13

6

7

15

TPR-102

240

1

TPR-202

2000

240

1

21

12

9

23

TPR-204

480

1

TPR-302

3000

240

1

26

17

9

28

TPR-304

480

1

TPR-402

4000

240

1

31

22

9

33

TPR-404

480

1

TPR-602

6000

240

1

42

33

9

44

TPR-604

480

1

TPR-802

8000

240

1

53

44

9

55

TPR-804

480

1

Specifications — Type TPR — Figure 1

TUFF-TUBE

THREE (TPF)

Dimensions (In.)

Model

Watts

Volts

Phase

A

B*

C**

D

TPF-302

3000

240

3

20

11

9

22

TPF-304

480

3

TPF-402

4000

240

3

23

14

9

25

TPF-404

480

3

TPF-602

6000

240

3

30

21

9

32

TPF-604

480

3

TPF-802

8000

240

3

37

28

9

39

TPF-804

480

3

TPF-1002

10000

240

3

44

35

9

46

TPF-1004

480

3

Specifications — Type TPF — Figure 2

*B Dimension is heated section.

**C Dimension is cold section.

*B Dimension is heated section.

**C Dimension is cold section.

A

C

B

D

7/8 Dia. each side

for 1/2 in. conduit

Tank Lip

Plastic guard cover removed
for illustration purposes.

D

Plastic guard cover removed
for illustration purposes.

Mounting Hole Location

7/8 Dia. each side

for 1/2 in. conduit

Tank Lip

A

C

B

Mounting Hole Location
