27
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 684-0123A Bracket, Belt Cover ..................... 1
2 710-0191 Screw, Hex Cap, 3/8-14 x 1.25 GR8 2
3 710-0237 Screw, Hx Cap, 5/16-24 x .625 GR5 3
4 710-0607 Screw, Hx Wash Hd Tapp, ..........
5/16-18 x .5
3
5 710-0672
710-1245B
Screw, Hx Cap — 28" S.T. Only —
5/16-24 x 1.25 GR5
Screw, Hx Cap — 33" and 45" S.T.
Only — 5/16-24 x .875 GR8
1
1
6 710-1008
710-0502
Screw, Hx Sems Tapp — 28" S.T.
Only — 3/8-16 x 1.875
Screw, Hx Sems Tapp — 33" and
45" S.T. Only — 3/8-16 x 1.25
4
4
7 712-0116 Nut, Hx Insert Jam Lk, 3/8-24 GR5 1
8 714-0118 Key, Square, 1/4 x 1.5 ................. 1
9 717-0882A Spacer, .56 — 28" S.T. Only ....... 1
10 731-2531 Cover, Belt ................................... 1
11 732-0303 Spring, Extension ........................ 1
12 736-0217 Washer, Lock .............................. 2
13 736-0242 Washer, Belleville, .34 x .872 x .06 4
14 736-0264 Washer, Flat, .33 x .63 x .0635 ... 3
15 736-0322 Washer, Flat, Hdn .45 x 1.25 x .164 1
16 738-0982
738-0215A
Screw, Shoulder — 28" S.T. Only —
.498 x 3.245:3/8-16
Screw, Shoulder — 33" and 45" S.T.
Only — .498 x 2.99:3/8-16
1
1
17 748-0234 Spacer, Shoulder ......................... 1
18 748-0418
736-0159
Spacer — 28" S.T. Only —
.331 x 1.01 x .36
Washer, Flat — 33" and 45" S.T.
Only — .349 x .879 x .063
1
1
19 750-1148A Spacer,— 28" S.T. Only —
1.02 x 1.63 x .1425
1
20 754-0131 V-Belt, 3/8 x 35.5 ......................... 1
21 756-0240 Pulley, Flat Idler, 3.0 OD ............. 1
22 756-0241B Pulley, Double, 3.25 OD: 2.75 OD 1
23 784-5726 Bracket, Idler ............................... 1
24 732-0705 Guide, Chute Cable ..................... 1
25 712-04064 Nut, Hx Flnge Insert Lk — 33" and
45" S.T. Only — 1/4-20 GrF
1
26 736-0173 Washer, Flat — 33" and 45" S.T.
Only — .28 x .74 x .o063
1
27 629-0071 Extension Cord, 110V, 3-prong ... 1
NOTE: Please add the applicable color code
below to the part number to order a replace-
ment part. For instance, if a part, numbered
700-xxxx, is painted Cub Yellow, the part num-
ber to order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Powder Black: 0637
