Cub Cadet 933 SWE - Manual (Page 25)

25
REF.
NO.
PART
NUMBER
DESCRIPTION QTY.
1 629-04010 Harness, Headlight Wire ............................. 1
2 646-0012 Cable Assembly, Auger/Drive Engagement 2
3 684-0053B Crank, Chute, 26.0 ...................................... 1
4 705-5218 Handle, Egagement, RH ............................. 1
5 705-5219 Handle, Egagement, LH .............................. 1
6 705-5266 Bracket, Chute Crank .................................. 1
7 710-0458 Screw, Carriage, 5/16-18 x 1.75 ................. 4
8 710-0572 Screw, Carriage, 5/16-18 x 2.5 ................... 4
9 710-1003 Screw, Hex Wash Hd Tapp, #10-16 x .625 2
10 710-1625 Screw, Oval Hd C/Sunk, #10-24 x 1.75 ...... 2
11 710-1878 Screw, Hex Patch Lock, 3/8-16 x 1,75 GR5 2
12 710-1879 Screw, Hex Patch Lock, 3/8-16 x .88 GR5 2
13 710-3015 Screw, Hex Cap, 1/4-20 x .75 GR5 ............. 2
14 711-0677 Ferrule, 5/16-18 x .312 Dia ......................... 1
15 712-0271 Nut, Hex Sems, 1/4-20 ................................ 1
16 712-04064 Nut, Hex Flange Insert Lock, 1/4-20 GrF .... 2
17 712-3010 Nut, Hex, 5/16-18 GR5 ............................... 4
18 714-0101 Pin, Internal Cotter ...................................... 1
19 714-0104 Pin, Internal Cotter ...................................... 4
20 720-0201A Knob, Crank ................................................ 1
21 720-0232 Knob, Shift .................................................. 2
22 720-0284 Knob, Wing Nut, 5/16-18 ............................. 4
23 725-0157 Tie, Cable .................................................... 2
24 725-1658 Lamp, Halogen, 27W .................................. 2
25 725-1672 Housing, Lamp ............................................ 2
26 726-0100 Cap, Push, 3/8 ............................................ 1
27 731-04069
777I22553
777I22554
777I22556
777I22363
777D09462
777D09460
777D09463
777D09465 Panel, Handle .............................................
Graphic, Left Turn/Auger Control .............
Graphic, Chute Tilt/Shift ...........................
Graphic, Starting Instr/Drive Control ........
Graphic, Drive/Auger Lock .......................
Graphic, Cub Cadet .................................
Graphic, 928 SWE — 28" S.T. Only ........
Graphic, 933 SWE — 33" S.T. Only ........
Graphic, 945 SWE — 45" S.T. Only ........
1
1
1
1
1
1
1
1
1
28 736-0105 Washer, Belleville, .375 x .87 x .063 ........... 4
29 736-0185 Washer, Flat, .375 x .738 x .063 ................. 1
30 736-0242 Washer, Belleville, .34 x .872 x .06 ............. 8
31 736-0275 Washer, Flat, .344 x .688 x .065 ................. 2
32 741-0475 Bushing, Plastic, .38 ID ............................... 1
33 746-0950A Cable Assembly, Trigger Control ................ 2
34 747-0624 Rod, Chute Crank ....................................... 1
35 747-0983A Rod, Lower Shift ......................................... 1
36 747-0997 Rod, Upper Shift ......................................... 1
37 747-1136 Retainer, Headlight ..................................... 2
38 749-0989A Handle, Upper LH ....................................... 1
39 749-0990A Handle, Upper RH ....................................... 1
40 749-0991 Handle, Lower ............................................. 1
41 750-0963 Connector, Shift Rod ................................... 1
NOTE: Please add the applicable color code
below to the part number to order a replace-
ment part. For instance, if a part, numbered
700-xxxx, is painted Cub Yellow, the part num-
ber to order would be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Powder Black: 0637
