29
Seat Assembly- Figure 18 and Parts List
Ref.
No. Part No. Description Qty.
1 00022560 Nut, Hex 3/8-16 Flange Lock 3
2 01000635 Lock Nut, Hex Flange, 5/16-18 4
3 01000937 Spacer, .412 x 1.125 x .44 2
4 01000960 Washer 2
5 01002634 Shoulder Screw, .50x2.345, 3/8-16 2
6 01002753 Grommet, 2.5 OD x 1.0 Long 2
7 01008141 Deck Lift Spring, Right Hand 1
8 01009432 Rops Assembly includes: 1
02002713 Canopy 1
9 02001122 Seat Assembly, w/ Suspension & Seat Belts 1
02002707 Seat Belt 1
10 02002091 Shoulder Bolt, 1/2 x 3/4, 3/8-16 1
11 02002418 Seat Latch 1
12 02002417 Seat Bracket 1
GD: 02001003-05/03/06
