11
72" Fabricated Cutter Deck - Parts List for Figure 6
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin, .125 Dia. x 1.0 1
2 00011925 Hex Cap Screw, 3/8-16, 3.75 6
3 00012158 Flat Washer, 3/8 6
4 00012428 Lock Nut, Nylon Insert, 1/2-13 4
5 00014608 Lock Nut, Nylon Insert, #10-32 16
6 00017778 Phillips Head Screw, #10-32 x 1/2 16
7 00022560 Flange Lock Hex Nut, 3/8-16 61
8 01000343 Complete Wheel, 5.00 Dia. 6
9 01000372 Carriage Bolt, 3/8-16 x .75 Lg. 44
10 01000385 Front Roller 4
11 01000398 Wheel Spacer 6
12 01000643 Carriage Bolt, 3/8-16 x 1 2
13 01001169 Grass Catcher Roller 2
14 01001745 Pin, 5/8 Dia. x 1.2 Lg. 4
15 01002010 Carriage Screw, 3/8-16 x 1.25 7
16 01003253 Torsion Spring, 0.4ID x 2.16Lg 1
17 01004304 Hex Index Washer Screw, 3/8-16, .5 8
18 01004685 Belt Cover Support 2
19 01005364 Deck Roller Mount Bracket 3
20 01005260 Anti-Scalp Wheel Front Mount Bracket 4
21 01005437 Outer Belt Cover Support Assembly 2
22 01005869 T-Handle Latch Draw 4
23 01008097 72 Deck Assembly 1
24 01008233 Roller Pin 1
25 01008514 Chute Bracket 1
26 01008526 Finger Guard 1
27 01009102 Pin, .375 x 14.06 1
28 01009300 Chute Bracket 1
29 01009705 Chute Deflector 1
30 01009843 Discharge Baffle Weldment 1
31 02000109 Pillow Block, Steel 3
32 02000110 Pillow Block, Bronze 1
33 02000447 Left Hand Deck Belt Cover 1
34 02000448 Right Hand Deck Belt Cover 1
35 02002632 Right Hand Deck Weldment Bracket 1
36 02002633 Left Hand Deck Weldment Bracket 1
