Cub Cadet 53AB5JEZ750 User Manual
Page 27
27
28.2HP Caterpillar Engine Assembly - Parts List for Figure 16
Ref
No Part No.
Description
Qty.
Ref
No
Part No.
Description
Qty.
1
00006131 Hex Nut, 3/8-16
1
30
01007088
Nut, M6 x 1, Lock
1
2
00011861 HHCS, 3/8-16, 2.25
1
31
01008531
Self Tapping Screw, #10-32 x .500
1
3
00012133 Hex Cap Screw, 1/4-20 x 1/2
9
32
01010119
Nut, 1/2-13, FlangeLock
4
4
00012168 Lock Washer, 5/16
5
33
02000302
Idler Pulley, 3.5 OD
1
5
00012226 Grease Fitting, 90°
1
34
02000305
Idler Arm Assembly includes:
1
6
00012609 Clevis Pin, 1/4 x 3/4
1
01000308
Bearing
2
7
00013406 Hex Cap Screw, 5/16-18 x .75
2
35
02000932
Drive Shaft
1
8
00013669 Screw, Hex Washer, 10-32 x 1/2
2
36
02001010
Engine, 28.2HP Cat Diesel
1
9
00014608 Lock Nut, Nylon Insert, 10-32
2
37
02001021
Engine Mounting Assembly
2
10 00021517 Key, 1/4 x 1/4 x 2.0
1
38
02001035
Engine Isolator
4
11 00022560 Flange Lock, Hex Nut, 3/8-16
3
39
02001037
Transmission Drive Pulley
1
12 00027279 Nylock Nut, 7/16-14
1
40
02001059
Throttle Cable Mounting Bracket
1
13 00083192 Idler Washer
2
41
02001069
CLutch Retainer Assembly
1
14 01000199 Extension Spring, 1.0 OD x 5.00
1
42
02001073
Muffler, 28.2HP Cat Diesel
1
15 01000389 Lock Washer, 7/16
4
43
02001076
Muffler Cover Assembly, Rear
1
16 01000393 Washer, .469 ID x .875 OD x .105
3
44
02001079
Muffler Cover Assembly, Front
1
17 01000505 Shoulder Bolt
1
45
02001080
HHCS, M12-1.25 x 25MM
16
18 01000512 Hex Cap Screw, 3/8-16 x 1.75
1
46
02001098
Washer, .53 ID x 2.13 OD x .134
4
19 01000635 Hexflange Lock Nut, 5/16-18
2
47
02001105
Muffler Mounting Bracket
1
20 01000720 Hex Cap Screw, M8-1.25 x 25MM
6
48
02001113
Clutch Brake, GT3.5-CT06D, Diesel
1
21 01000925 Self Tapping Screw, 1/4-20 x 0.375
2
49
02001116
V-Belt
1
22 01001042 Screw, M6-1.0 x 12MM
2
50
02001133
Throttle Control Cable, 49.0
1
23 01001082 Hex Cap Screw, 7/16-20 x 2.00
1
51
02002158
Engine Spacer, 1.125 x 1.75 x .438
1
24 01002070 Throttle Clamp
1
52
02002402
Hex Cap Screw, M8-1.25 x 30MM
3
25 01002766 Lock Nut, 1/4-20
18
53
02002407
Idler Spring
1
26 01002771 Cotter Pin, .072 x 1.12 Long
1
54
02002411
Hex Cap Screw, M8-1.25 x 12MM
1
27 01003113 Hex Cap Screw, 1/2-13 x 3.25
4
55
02002413
Hex Cap Screw, M10-1.25 x 25MM
3
28 01003561 Hex Nut, M8 x 1.2, Nylon Top Lock
1
56
02002425
Worm Clamp, 4.125 - 7.00
2
29 01005314 Flat Washer, 7/16 ID x 1.75 OD x .25
1
57
02002479
Exhaust Manifold Shroud Assembly
1
Note: Engine Oil 15W40 02002058
