P RESARIO N OTEBOOK M AINTENANCE AND S ERVICE G UIDE 1200XL S ERIES R EMOVAL S EQUENCE 9
Presario 1200 Series
Models: XL101-XL113, XL115, XL118-XL127
Hard Drive Ribbon Cable
The ribbon cable position for the hard drive is shown below.
Д Д Д Д CAUTION: When servicing this computer, ensure that cables are placed in their
proper location during the reassembly process. Improper cable placement can
damage the computer.
