Figure 12: IP management diagram
PC/Workstation with IE Browser Managed Industrial Switch
IP Address: 192.168.0.x IP Address: 192.168.0.100
1. RJ645 /UTP Cable
Login to the Managed Switch
1. Use Internet Explorer 6.0 or above Web browser. Enter the IP address
http://192.168.0.100 (the factory-default IP address or that you have just
changed in the console) to access the Web interface.
2. When the following dialog box appears, please enter the default
password "admin" (or the password you have changed via console). The
login screen in Figure 13 appears.
• Default IP Address: 192.168.0.100
• Default Username: admin
• Default Password: admin
12 of 13 P/N 1069666-EN • REV 1.01 • ISS 14JUL10
