5. The PoE Provision Process
While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be
transferred over existing CAT-5 cables. Without proper preparation, doing so may result in damage to devices that are not
designed to support provision of power over their network interfaces.
The PSE is the manager of the PoE process. In the beginning, only small voltage level is induced on the port's output, till a valid
PD is detected during the Detection period. The PSE may choose to perform classification, to estimate the amount of power to
be consumed by this PD. After a time-controlled start-up, the PSE begins supplying the 48 VDC level to the PD, till it is
physically or electrically disconnected. Upon disconnection, voltage and power shut down.
Since the PSE is responsible for the PoE process timing, it is the one generating the probing signals prior to operating the PD
and monitoring the various scenarios that may occur during operation.
All probing is done using voltage induction and current measurement in return.
Stages of powering up a PoE link
Stage Action
Volts specified
per 802.3af Volts managed
by chipset
Detection
Measure whether powered device has the correct signature
resistance of 15–33 KΩ
2.7-10.0 1.8–10.0
Classification Measure which power level class the resistor indicates 14.5-20.5 12.5–25.0
Startup Where the powered device will startup >42 >38
Normal operation Supply power to device 36-57 25.0–60.0
5.1 Line Detection
Before power is applied, safety dictates that it must first be ensured that a valid PD is connected to the PSE's output. This
process is referred to as "line detection", and involves the PSE seeking a specific, 25 KΩ signature resistor. Detection of this
signature indicates that a valid PD is connected, and that provision of power to the device may commence.
The signature resistor lies in the PD's PoE front-end, isolated from the rest of the PD's circuitries till detection is certified.
5.2 Classification
Once a PD is detected, the PSE may optionally perform classification, to determine the maximal power a PD is to consume. The
PSE induces 15.5-20.5 VDC, limited to 100 mA, for a period of 10 to 75 ms responded by a certain current consumption by the
PD, indicating its power class.
The PD is assigned to one of 5 classes: 0 (default class) indicates that full 15.4 watts should be provided, 1-3 indicate various
required power levels and 4 is reserved for future use. PDs that do not support classification are assigned to class 0. Special
care must be employed in the definition of class thresholds, as classification may be affected by cable losses.
Classifying a PD according to its power consumption may assist a PoE system in optimizing its power distribution. Such a
system typically suffers from lack of power resources, so that efficient power management based on classification results may
reduce total system costs.
5.3 Start-up
Once line detection and optional classification stages are completed, the PSE must switch from low voltage to its full voltage
capacity (44-57 Volts) over a minimal amount of time (above 15 microseconds).
A gradual startup is required, as a sudden rise in voltage (reaching high frequencies) would introduce noise on the data lines.
