Interlogix ES2001-4P-4T User Manual
Page 12
IFS ES2001-4P-4T User Manual
12
Figure 2-6
End node or Switch connection
Cable distance for Switch
The cable distance between the ES2001-4P-4T and PC should not exceed 100 meter for UTP/STP
cable.
Make sure the wiring is correct
It Category 3/4/5 cable can be used in 10 Mbps operation. To reliably operate your network at
100Mbps, you must use an Unshielded Twisted-Pair (UTP) Category 5 cable, or better Data Grade
cabling. Use of CAT3 or CAT4 cables with 100Mbps may cause data loss.
