IFS MC355-1T/1S User Manual
Fiber Optic Cable Connection Parameters
The wiring Details are as follows:
Fiber Optical Patch Cables
Standard
Fiber
Diameter (micron)
Modal Bandwidth
(MHz * km)
Max. Distance
(meters)
1000Base-SX Multi-mode
62.5
62.5
50
50
100
200
400
500
220
275
500
550
Multi-mode 62.5
50
50
5
4
5
550
1000Base-LX
Single-mode 9
N/A
5000*
