6
1.4 Product Specifications
Model MC350-1T-2S
Hardware Specification
10/100/1000Base-T Ports 1
SFP Interfaces
2 1000Base-SX/LX/BX SFP interfaces (Port-1 and Port-2)
Compatible with 100Base-FX SFP
Dimensions (W x D x H) 135 x 87 x 32mm
Weight 505g
Power Requirements
DC 12~48V, Redundant power with polarity reverse protection
function. AC 24V Power Adapter
Power Consumption /
Dissipation
8.4 watts / 28BTU
Installation DIN Rail Kit and Wall Mount Ear
Converter Specification
Processing Scheme Store-and-Forward
Flow Control
Back pressure for half duplex
IEEE 802.3x Pause Frame for full duplex
Fabric 6Gbps
Throughput (packet per second) 4.46Mpps
Maximum Transmission Unit 9216bytes
Network Cables
10/100/1000Base-T:
Cat. 3, 4, 5, 5e, 6 UTP cable (100meters, max.)
EIA/TIA-568 100-ohm STP (100meters, max.)
1000Base-SX :
50/125μm or 62.5/125μm multi-mode fiber optic cable, up to
550m (vary on SFP module)
1000Base-LX :
9/125μm single-mode fiber optic cable, up to
10/20/30/40/50/70/120 kilometers (vary on SFP module)
100Base-FX :
50/125μm or 62.5/125μm multi-mode fiber optic cable, up to
2 kilometers (vary on SFP module)
9/125μm single-mode fiber optic cable, up to 20/40/60
kilometers (vary on SFP module)
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
