Interlogix MC350-1T-2S - Manual (Page 11)

11
2.1.2 LED Indicators
System
LED Color Function
P1 Green Lit: indicate power 1 has power.
P2
Green
Lit: indicate power 2 has power.
FAULT
Green
Lit: indicate either power 1 or power 2 has no power.
Per 10/100/1000T Port
LED Color Function
100
LNK/ACT
Orange
Lit: indicate the link through that port is successfully established at 100Mbps or
10Mbps.
Blink:
indicate that the Switch is actively sending or receiving data over that port.
Off: indicate the link through that port is successfully established at 1000Mbps.
1000
LNK/ACT Green Lit: indicate the link through that port is successfully established at 1000Mbps or
10Mbps.
Blink:
indicate that the Switch is actively sending or receiving data over that port.
Off: indicate the link through that port is successfully established at 100Mbps.
Per 100 / 1000X SFP Slots
LED Color Function
LNK/ACT Green Lit: indicate the link through that port is successfully established at 100Mbps or
1000Mbps.
Blink:
indicate that the Converter is actively sending or receiving data over that
port or the port operate.
