Installation Steps

Step

Unpack the Industrial Gigabit Media Converter.

Step 2:

Check whether the DIN-Rail is screwed on the Industrial Gigabit Media Converter. (Please refer to DIN-Rail

Mounting section for DIN-Rail installation if the DIN-Rail is not screwed on the Industrial Gigabit Media Converter).

If you want to wall-mount the Industrial Gigabit Media Converter, then please refer to the Wall Mount Plate

Mounting section for wall mount plate installation.

Step 3:

To hang the Industrial Gigabit Media Converter on the DIN-Rail track or wall, please refer to the Mounting

Installation section.

Step 4:

Power on the Industrial Gigabit Media Converter. (Please refer to the Wiring of the Power Inputs section for power

input) The power LED on the Industrial Gigabit Media Converter will light up. Please refer to the LED Indicators

section for the functions of LED lights.

Step 5:

Prepare the twisted-pair, straight through Category 5 cable for Ethernet connection.

Step 6:

Insert one side of category 5 cable into the Industrial Gigabit Media Converter Ethernet port (RJ-45 port) while the

other side of category 5 cable into the network devices' Ethernet port (RJ-45 port), ex: switch, PC or server. The

UTP port (RJ-45) LED on the Industrial Gigabit Media Converter will light up when the cable is connected with the

network device. Please refer to the LED Indicators section for the functions of LED lights.

Step 7:

When all connections are all set and LED lights all show normally, the installation is complete.

Be sure the connected network devices support MDI/MDI-X. If it does not support

then

use the crossover category 5 cable.
