Page 17
IFS MC250-4T/1CXT User Manual 11
1 2 3 4 5 6
Note:
The wire gauge for the terminal block should be in the
range between 12 ~ 24 AWG.
The alarm relay circuit accepts up to 30V, max. 3A currents.
Mounting Installation
This section describes how to mount the MC250-4T/1CXT and
make connections to it. Please read the following sections and
perform the procedures in the order presented.
Note:
In the installation steps below, this Manual uses the GE-
DSGH-8 (IFS 8 Port Industrial Gigabit Switch) as an example.
However, the steps for any IFS Industrial Switch & Industrial
Media Converter are similar.
Insert the wires into the fault alarm contacts
